Model 540
Model 540
Experience an exceptionally smooth ride, even when the seas turn rough. The Oceanic hull design and intelligent engineering work together to minimize impact and maximize control—offering unwavering stability that keeps every journey comfortable and composed.
SPECIFICATIONS
| L.O.A (Length Overall) | 5.40 m |
| Beam | 2.40 m |
| Fuel Capacity | 1 x 86 L |
| Tube Diameter | 0.50 m |
| Tube Material | 1670 DTX ORCA PENNEL-FLIPO |
| Max HP | 140 HP |
| Number of Passengers | 7 |
| Weight | 450 kg |
| Valves | Leafield |
| Separate air chambers | 2 + 2 on each side |
| Design Category | Tenders,Recreational & Professional Purposes |
BASIC GEAR
Fuel & Water Reservoirs
Console Features
Seating
Storage Compartments
️ Additional Equipment
Air Chambers
- 1 x 86-liter fuel tank with filling cap and ventilation
- Fuel float in the reservoir
- Bow water tank with pressure pump and handheld shower phone holder
Console Features
- Console with railing and windscreen
- Polyurethane steering wheel
- Oceanic 8-position switch panel with flush buttons and fuses
- Lockers on the console
- Built-in marine horn
- USB port
Seating
- Driver’s seat in semi-upright position
- Forward seat in front of the console
- Rear three-seater reclining sofa
- Bow seating
- Complete set of upholstery
Storage Compartments
- Locker in the polyester bow area of the vessel
- Locker beneath the bow seat
- Locker with door inside the console
- Locker at the driver’s position
- Locker beneath the three-seater sofa
- Stern lockers in hatch lids
️ Additional Equipment
- Shock absorbers on lockers
- Bilge pump
- 2 self-draining scuppers
- Boarding ladder
- Mast with navigation LED lights
- 2 platforms at the stern
Air Chambers
- ORCA 1670 DTX Pennel Flipo chambers
- Single perimeter 9mm MASIF neoprene rubber (rubber, not PVC)
- 6 airtight chambers (3 on each side)
OPTIONAL GEAR
- Foam teak deck coating for enhanced aesthetic and non-slip surface
- Custom gelcoat finish (hull color and coating of choice)
- 500W electric windlass with stainless steel bow roller and galvanized chain
- Seastar hydraulic steering system for precision handling
- Garmin GPS 923xsv or 1223xsv with GT51 transducer and preloaded maps
- Dual battery system ensuring reliable energy distribution
- Fusion MSRA210 NMEA stereo system with 2 high-quality speakers
- LED lighting throughout the vessel for atmosphere and efficiency
- Underwater lights for visibility and ambiance at night
- Stainless steel grab handles on the stern side rails
- INOX rollbar complete with retractable/telescopic awning
- Console cover for protection against the elements
- Hull cover to shield the body during storage
- Stainless steel awning with support struts
- ORCA Hypalon air tube (Carbon or Perlage finish) for durability and style
- Safety equipment certified for coastal cruising
- Trailer for easy transportation and launch
